Used TECNA Rocker Welder

WSI-SELECT – In-Stock and For Sale at Weld Systems Integrators

WSI Serial #: W-4003

Used TECNA rocker welder [ WSI stock / serial #: W-4003 ] FOR SALE at Weld Systems Integrators. This welder was used in light production for several years, they are very clean, have been fully tested, repaired as required, and meet new welder production requirements.

New footswitch installed, LOTO devices installed on air and water inlets. Arms are adjustable, short throat 15″, 363#’s of force, 2.4″ electrode opening. Deep throat 27.6″, 198#’s of force, 4.1″ electrode opening.

WSI maintains an IN-STOCK inventory of new and used resistance welding equipment at our Warrensville Heights, Ohio location for quick shipment and delivery. Contact our knowledgeable sales team at 844-WSI-WELD or +1-216-475-5629 for immediate assistance.

EQUIPMENT QUOTE
Quote RequestSpecifications

Please submit the following form to request additional information.

Enter WSI Serial #: W-4003 on the following quote request form.

If you have any questions on WSI Select – IN-STOCK equipment available from Weld Systems Integrators, please call 844-WSI-WELD or +1-216-475-5629 and ask to speak with a WSI Engineer.

    Contact Information



    * Required


    If you experience any issues submitting this form, give us a call at 844-WSI-WELD or +1-216-475-5629.

    SPECIFICATIONS WSI Stock / Serial #: W-4003
    Manufacturer Name: TECNA
    Type: Rocker Welder
    Mfg. Model #: WTR-4647
    KVA: 20
    Voltage 220 / 440
    Phase: Single
    Low Secondary Voltage: 4
    High Secondary Voltage: 4
    # of Tap Switch Positions: n / a
    Max. Secondary Current: 12,000
    Throat Depth to Center of Platens: n / a
    Platen Size: n / a
    Throat Depth to Center of Electrodes: 27.6″
    Arm Diameter: 1.57″
    Holder Diameter: 1″
    Electrode Size: #1MT
    Cylinder Type: Air
    Cylinder Diameter: n / a
    Cylinder Stroke: 4.1″
    Maximum Weld Force, #’s: 363
    Weld Control Manufacturer: TECNA
    Weld Control Mfg. Model #: TE-90
    Disconnect Size: n / a
    Initiation: 2 Stage Foot Switch
    General Condition: Welders were used in light production for several years, they are very clean, have been fully tested, repaired as required, and meet new welder production requirements.
    Additional Details: New foot switch installed, LOTO devices installed on air and water inlets. Arms are adjustable, short throat 15″, 363#’s of force, 2.4″ electrode opening. Deep throat 27.6″, 198#’s of force, 4.1″ electrode opening.
    Warranty: 6 Months
    Availability: Immediate
