NEW RoMan TDC-5598 MFDC / Inverter Power Supply
WSI-SELECT – In-Stock and For Sale at Weld Systems Integrators
WSI Serial #: WSI-3682
RoMan Manufacturing 160kVA Size 3 MFDC / Inverter Power Supply [ Model #: TDC-5598 | WSI serial #: WSI-3682 ] IN-STOCK at Weld Systems Integrators.
RoMan’s lightweight MFDC water-cooled transformers are ideal for robotic and fixture spot welding applications. With over-temperature thermoswitch protection and fully epoxy encapsulated to ensure long life, it is also available in 500 and 800 Volt, 1,000 Hz.
WSI is a RoMan resistance welding transformers and power supplies distributor, maintaining an IN-STOCK inventory at our Warrensville Heights, Ohio location for quick shipment and delivery. Contact our knowledgeable sales team at 844-WSI-WELD or +1-216-475-5629 for immediate assistance.
IN-STOCK Inventory: [product_stock id=”19686″]
EQUIPMENT QUOTEPlease submit the following form to request additional information.
Enter WSI Serial #: WSI-3682 on the following quote request form.
If you have any questions on WSI Select – IN-STOCK equipment available from Weld Systems Integrators, please call 844-WSI-WELD or +1-216-475-5629 and ask to speak with a WSI Engineer.
SPECIFICATIONS | Serial #: WSI-3682 |
---|---|
Manufacturer name: | RoMan Manufacturing |
Type: | MFDC / Inverter Power Supply |
Mfg. model #: | TDC-5598 |
kVA rating @ 50% duty cycle: | 160 kVA |
Size: | 3 |
Volts: | 650 |
Frame size: | S |
SECONDARY TURN RATIO & VOLTAGE | |
Tap 1 | |
> Turns ratio: | 72:1 |
> Volts: | 9.02 |
Tap 2 | |
> Turns ratio: | 50:1 |
> Volts: | 13:1 |
Drawing (PDF): | 5598 |
Rating curve: | RC-5598 |
RWMA pad size: | N / A |
Approx. weight (lbs.) | 70 |
General condition: | NEW |
Additional details: | – |
Warranty: | 1 Year |
Availability: | Immediate |
DRAWING [ PDF ]
RoMan MFDC / Inverter Power Supply – TDC-5598 Drawing
RATING CURVE [ PDF ]
RoMan MFDC / Inverter Power Supply – TDC-5598 Rating Curve
LOAD CHART [ PDF ]
