SOLD – Used Taylor Winfield Bench Welder FOR SALE from Weld Systems Integrators (WSI)
WSI Stock / Serial #: 20596
SOLD – Remanufactured Taylor Winfield bench welder mounted on pedestal, in excellent condition. New cylinder, air prep, air valve, air hose, water hose, manifold, strainer, ball valves, electrode holders, electrodes, shunts, transformer flushed and tested, new E-stop installed. Completely tested.
Used Taylor Winfield bench welder, original mfg. model #EB2-8-10 Air FOR SALE from Weld Systems Integrators. Immediate availability. Features include – 440 VAC, single-phase, 10 KVA, 2″ diameter weld cylinder, 1.5″ stroke, 8″ throat depth to center of electrodes and Entron EN1000-300E weld controls.
QUOTE REQUEST!
Please submit the following form to request additional information.
If you have any questions on used equipment available from Weld Systems Integrators, please call 844-WSI-WELD or +1-216-475-5629 and ask to speak with a WSI Engineer.
| SPECIFICATIONS | WSI Stock / Serial #: 20596 |
|---|---|
| Manufacturer Name: | Taylor Winfield |
| Type: | Bench welder mounted on pedestal |
| Mfg. Model #: | EB2-8-10 Air |
| KVA: | 10 |
| Voltage | 440 |
| Phase: | Single |
| Low Secondary Voltage: | 1.5 |
| High Secondary Voltage: | 3 |
| # of Tap Switch Positions: | Series / Parallel |
| Max. Secondary Current: | 15 K Amps |
| Throat Depth to Center of Platens: | n / a |
| Platen Size: | n / a |
| Throat Depth to Center of Electrodes: | 8″ |
| Arm Diameter: | 2″ |
| Holder Diameter: | 1″ |
| Electrode Size: | 5 RW |
| Cylinder Type: | Air |
| Cylinder Diameter: | 2″ |
| Cylinder Stroke: | 1.5″ |
| Maximum Weld Force, #’s: | 260 lbs. |
| Weld Control Manufacturer: | Entron |
| Weld Control Mfg. Model #: | EN1000-300E |
| Disconnect Size: | n / a |
| Initiation: | 2 stage foot switch |
| General Condition: | Great working welder with new cylinder, air prep, air valve, air hose, water hose, manifold, strainer, ball valves, electrode holders, electrodes, shunts, transformer flushed and tested, new E-stop installed. |
| Additional Details: | – |
| Warranty: | 6 months |
| Availability: | Immediate |
SOLD – Used Taylor Winfield Bench Welder – WSI Stock / Serial #: 20596. If you’re looking for a similar spot welder, please submit the following form.
